Download PDF• Instant service is the prerequisite of healthcare industries. By offering excellent services, Trio has achieved the paramount place in the service industries.
• Trio’s bed and stretcher elevators series follow persistent compassionate thinking, By applying destination control and group control mechanism, TRIO fulfills the intellectual elevator travel and reduces the patients’ waiting period to minimum extent.
| • Automatic Fan Switch off | • Fire Alarm Operation |
| • Emergency Alarm and Light | • Home Landing |
| • Attendant Service | • Next Landing Operation |
| • Automatic Rescue Operation | • Motor Overheat Protection |
| • Electronic Multi Beam Infrared Door Detector | • Phase Failure Protection |
| • Intercom Facility |
| • Overload Warning | • BMS Compatibility |
| • Independent Service | • Navigo (Destination Based Dispatch System) |
| • Voice Annunciator | • Car Call Cancellation |
| • Site Programmability | • Load Based Priority Call Operation |
| • Multi – Car Group Control Operation ( upto 8 car group) | • Removal of Elevator from the group and operation in independent mode |
| • Hall Lantern and Car Arrival Chime | • Car Light and Display Illumination Power Saver |
| • Proximity Card Reader Access | • Elevator Compatibility Building Integrated Services |
| • Biometric Access | • Elevator Remote Access |
| • Parking Shutoff | • Elevator Monitoring System |
Civil Dimensions for Streacher Elevators above hoistway / Mrl (Geared & Gearless)
| CAPACITY | SPEED | LOAD | LIFT WELL WXD | PLATFORM WXD | CAR INSIDE WXD | MACHINE CENTRE OPEN | MACHINE ROOM (DEPTH) | MACHINE ROOM (WIDTH) | PIT | OVER HEAD (Min.) | CAR INSIDE SQ.MTR. | |||
| PERSONS | MPS | K.G | W | D | W | D | W | D | W | w | D | |||
| 16 | 1.0/1.5 | 1088 | 2000 | 2900 | 1160 | 2550 | 1100 | 2400 | 900 | 4700 | 4850 | 1600 | 4800 | 2.64 |
| 20 | 1.0/1.5 | 1360 | 2200 | 2900 | 1360 | 2550 | 1300 | 2400 | 1000 | 4900 | 4850 | 1800 | 4800 | 3.12 |
| 26 | 1.0/1.5 | 1768 | 2600 | 2900 | 1660 | 2550 | 1600 | 2400 | 1200 | 5300 | 4850 | 2000 | 4800 | 3.84 |
DISCLAIMER : The Sizes & Dimensions are subject to change anytime @ TRIO’s sole discretion.
